The Neles Series X modular ball valve features a heavy‑duty stem‑to‑ball connection for its seat‑supported variants. Application‑specific seat selection ensures sustained sealing performance throughout valve service life. This valve series complies with contemporary industrial safety and emissions requirements.
Specifications
- Construction
- Flanged, seat supported, full and reduced bore ball valve
- Size range
- DN 25 – 200 / NPS 1” – 8”
- Face to face
- ASME B16.10
- Design standard
- ASME B16.34, API 608
- Pressure ratings
- EN PN 10 - 100, ASME 150 - 600
- Temperature range
- -200 °C … +600 °C / -320°F … +1110 °F
