Neles Series X modular ball valve: trunnion mounted design with robust stem-to-ball connection. Application-matched seats provide long-term tightness. Optional Neles Q-trim™ anti-cavitation, noise attenuation trim; superior to competing ball control valves. Complies with modern safety and emission requirements.
Specifications
- Construction
- Flanged, trunnion mounted, full bore ball valve
- Size range
- DN 50 – 600 / NPS 2” – 24” (trunnion mounted, full bore)
- Standards
- ASME B16.34, API 608, API 6D (on request)
- Face to face
- ASME B16.10
- Pressure ratings
- EN PN 10 - 40, ASME 150 - 300
- Temperature range
- -50 °C … +600 °C / -60 °F … +1110 °F
