Specifications
- SERIES
- I & LI
- TORQUE OUTPUT
- 17-68 Nm, 150-600 lb-in, 12-50 lb-ft, Series I;113-339 Nm, 1000-3000 lb-in, 83-250 lb-ft, Series LI
- DUTY CYCLE*)
- 75% @ 40°C / 104°F
- OPERATION
- Reversing
- ENCLOSURE**)
- NEMA 4/4X or NEMA 4/4X/7&9
- TEMPERATURE RANGE
- -40°C to 66°C / -40°F to 150°F
- VOLTAGE
- 115VAC, 230VAC;*) Duty Cycle is 55% for 3000 lb-in models;**) CSA (C US) Certification standard on most models
