Complying with ASME (ANSI) B73.1 design standards, Durco Mark 3 process pumps are equipped with multiple field‑proven features that boost operational reliability and hydraulic performance. A broad selection of configurations is offered: mechanical‑sealed, dynamic‑sealed, sealless magnetic‑drive, low‑flow, self‑priming and recessed‑impeller variants. This versatile pump platform delivers flexible, wide‑ranging pumping solutions for an extensive variety of industrial applications.
Specifications
- ASME
- B73.1 Specification for Horizontal End Suction Centrifugal Pumps for Chemical Process
- Flows
- to 4540 m3/h (20000 gpm)
- Heads
- to 215 m (700 ft)
- Pressures to
- 27 bar (400 psi)
- Temperatures from
- -75°C (-100°F) to 370°C (700°F)
- Size Range
- Sizes from 25 mm (1 in) to 200 mm (8 in)
