Neles Easyflow JT angle stem tank bottom valves adopt compact construction, offering extra actuator clearance for insulated pressure vessels. Its large port creates an unobstructed flow passage to fast fill or drain tanks. Quarter-turn action and direct actuator mounting simplify automation work. Optional cavity fill and T-port designs for JT series reduce dead volume to the minimum and enable full media draining from the valve.
Specifications
- Nominal diameter
- DN25 – DN150 (NPS 1 – 6)
- Pressure rating
- Class 150
- Flange accommodation
- ASME B16.5 Class 150
- Face to face dimensions
- Manufacturers standard
- Vacuum rating
- 29.91 inch Hg gauge (759.98 mm Hg gauge or 2x10-2 Torr or 4x10-4 psia or 99.99% vacuum)
- Leakage
- No visible leakage
- Testing
- API 598
- Standards followed
- BS EN 17292, ASME B16.34, API 598, BS EN 12266
- Note
- The main dimensions of the valve assembly needs to be considered during the installation.
